Projetando uma Arquitetura de Scraping Confiavel

Beyond Scripts: Why Architecture Matters

A single-file scraper works fine for a hundred pages. But when you need to collect millions of data points across dozens of target sites on a recurring schedule, you need a system — not a script. A reliable scraping architecture separates concerns into independent components that can be scaled, monitored, and recovered independently.

This guide walks through the design of a production scraping system, from URL scheduling through proxy management to data storage. Every component is illustrated with code and connected to the ProxyHat proxy infrastructure.

A well-architected scraper treats data collection as an engineering problem, not a hacking problem. Each component has a single responsibility, clear interfaces, and observable behavior.

System Architecture Overview

A production scraping system consists of six core components:

┌─────────────┐     ┌──────────────┐     ┌─────────────────┐
│  Scheduler   │────▶│  URL Queue   │────▶│  Crawler Pool   │
│  (cron/API)  │     │  (Redis)     │     │  (workers)      │
└─────────────┘     └──────────────┘     └────────┬────────┘
                                                   │
                                          ┌────────▼────────┐
                                          │  Proxy Layer     │
                                          │  (ProxyHat)      │
                                          └────────┬────────┘
                                                   │
                                          ┌────────▼────────┐
                                          │  Parser          │
                                          │  (extract data)  │
                                          └────────┬────────┘
                                                   │
                    ┌──────────────┐      ┌────────▼────────┐
                    │  Monitoring  │◀─────│  Storage         │
                    │  (metrics)   │      │  (DB / files)    │
                    └──────────────┘      └─────────────────┘

Component	Responsibility	Technology
Scheduler	Decides what to scrape and when	Cron, Celery Beat, Bull
URL Queue	Buffers URLs with priority and deduplication	Redis, RabbitMQ, SQS
Crawler Pool	Fetches pages concurrently	asyncio, goroutines, worker threads
Proxy Layer	Routes requests through rotating proxies	ProxyHat gateway
Parser	Extracts structured data from HTML/JSON	BeautifulSoup, cheerio, goquery
Storage	Persists extracted data	PostgreSQL, MongoDB, S3
Monitoring	Tracks health and performance	Prometheus, logging, alerts

Component 1: Scheduler

The scheduler decides which URLs to crawl and when. It manages crawl frequency, priority levels, and ensures no URL is scraped more often than necessary.

import redis
import json
import time
from datetime import datetime, timedelta
class CrawlScheduler:
    """Manages crawl schedules and feeds URLs to the queue."""
    def __init__(self, redis_url: str = "redis://localhost:6379"):
        self.redis = redis.from_url(redis_url)
        self.queue_key = "scraper:url_queue"
        self.schedule_key = "scraper:schedules"
        self.seen_key = "scraper:seen_urls"
    def add_schedule(self, name: str, urls: list[str], interval_hours: int, priority: int = 5):
        """Register a recurring crawl job."""
        self.redis.hset(self.schedule_key, name, json.dumps({
            "urls": urls,
            "interval_hours": interval_hours,
            "priority": priority,
            "last_run": None,
        }))
    def tick(self):
        """Check all schedules and enqueue URLs that are due."""
        schedules = self.redis.hgetall(self.schedule_key)
        enqueued = 0
        for name, data in schedules.items():
            schedule = json.loads(data)
            last_run = schedule.get("last_run")
            interval = timedelta(hours=schedule["interval_hours"])
            if last_run and datetime.fromisoformat(last_run) + interval > datetime.utcnow():
                continue
            for url in schedule["urls"]:
                self.enqueue(url, priority=schedule["priority"])
                enqueued += 1
            schedule["last_run"] = datetime.utcnow().isoformat()
            self.redis.hset(self.schedule_key, name, json.dumps(schedule))
        return enqueued
    def enqueue(self, url: str, priority: int = 5):
        """Add a URL to the crawl queue with deduplication."""
        # Skip if recently seen (within 1 hour)
        if self.redis.sismember(self.seen_key, url):
            return False
        self.redis.zadd(self.queue_key, {
            json.dumps({"url": url, "enqueued_at": time.time()}): priority
        })
        self.redis.sadd(self.seen_key, url)
        self.redis.expire(self.seen_key, 3600)  # 1-hour dedup window
        return True
    def dequeue(self, batch_size: int = 10) -> list[dict]:
        """Pull the highest-priority URLs from the queue."""
        items = self.redis.zpopmax(self.queue_key, batch_size)
        return [json.loads(item) for item, score in items]
    @property
    def queue_size(self) -> int:
        return self.redis.zcard(self.queue_key)
# Usage
scheduler = CrawlScheduler()
scheduler.add_schedule(
    name="product_prices",
    urls=[f"https://example.com/product/{i}" for i in range(1, 1001)],
    interval_hours=6,
    priority=8,
)
scheduler.add_schedule(
    name="competitor_pages",
    urls=["https://competitor.com/pricing", "https://competitor.com/features"],
    interval_hours=24,
    priority=5,
)
# Run every minute via cron
enqueued = scheduler.tick()
print(f"Enqueued {enqueued} URLs, queue size: {scheduler.queue_size}")

Component 2: URL Queue

The queue decouples scheduling from crawling. It provides priority ordering, backpressure, and persistence — so no URLs are lost if a crawler crashes.

// Node.js queue with Bull
const Queue = require('bull');
const crawlQueue = new Queue('crawl', 'redis://localhost:6379', {
  defaultJobOptions: {
    attempts: 3,
    backoff: { type: 'exponential', delay: 2000 },
    removeOnComplete: 100,
    removeOnFail: 500,
  },
});
// Add URLs with priority (lower number = higher priority)
async function enqueueUrls(urls, priority = 5) {
  const jobs = urls.map(url =>
    crawlQueue.add(
      { url, enqueuedAt: Date.now() },
      { priority, jobId: url } // jobId for deduplication
    )
  );
  await Promise.all(jobs);
  console.log(`Enqueued ${urls.length} URLs`);
}
// Worker processes URLs
crawlQueue.process(10, async (job) => {
  const { url } = job.data;
  // Crawl logic here (see Crawler Pool below)
  return { url, status: 'completed' };
});
crawlQueue.on('failed', (job, err) => {
  console.error(`Job ${job.id} failed: ${err.message}`);
});

Component 3: Crawler Pool

The crawler pool fetches pages concurrently through the proxy middleware layer. It manages concurrency limits, handles retries, and passes raw responses to the parser.

import asyncio
import aiohttp
import uuid
import time
from typing import Optional
class CrawlerPool:
    """Concurrent crawler with proxy rotation and retry logic."""
    def __init__(
        self,
        concurrency: int = 30,
        max_retries: int = 3,
        timeout: int = 30,
    ):
        self.concurrency = concurrency
        self.max_retries = max_retries
        self.timeout = aiohttp.ClientTimeout(total=timeout)
        self.semaphore = asyncio.Semaphore(concurrency)
        self.stats = {"success": 0, "failed": 0, "retries": 0}
    def _get_proxy(self, country: Optional[str] = None) -> str:
        session_id = uuid.uuid4().hex[:8]
        username = f"USERNAME-session-{session_id}"
        if country:
            username += f"-country-{country}"
        return f"http://{username}:PASSWORD@gate.proxyhat.com:8080"
    async def fetch(
        self,
        session: aiohttp.ClientSession,
        url: str,
        country: Optional[str] = None,
    ) -> dict:
        async with self.semaphore:
            for attempt in range(self.max_retries + 1):
                proxy = self._get_proxy(country)
                start = time.time()
                try:
                    async with session.get(
                        url, proxy=proxy, timeout=self.timeout,
                        headers={
                            "User-Agent": "Mozilla/5.0 (Windows NT 10.0; Win64; x64) "
                                          "AppleWebKit/537.36 Chrome/131.0.0.0 Safari/537.36",
                            "Accept": "text/html,application/xhtml+xml,*/*;q=0.8",
                        },
                    ) as response:
                        body = await response.text()
                        latency = time.time() - start
                        if response.status in (403, 429, 503) and attempt < self.max_retries:
                            self.stats["retries"] += 1
                            await asyncio.sleep(2 ** attempt)
                            continue
                        if response.status < 400:
                            self.stats["success"] += 1
                        else:
                            self.stats["failed"] += 1
                        return {
                            "url": url,
                            "status": response.status,
                            "body": body,
                            "latency": latency,
                            "success": response.status < 400,
                        }
                except Exception as e:
                    if attempt < self.max_retries:
                        self.stats["retries"] += 1
                        await asyncio.sleep(2 ** attempt)
                        continue
                    self.stats["failed"] += 1
                    return {
                        "url": url,
                        "error": str(e),
                        "latency": time.time() - start,
                        "success": False,
                    }
    async def crawl(self, urls: list[str], country: Optional[str] = None) -> list[dict]:
        async with aiohttp.ClientSession() as session:
            tasks = [self.fetch(session, url, country) for url in urls]
            return await asyncio.gather(*tasks)
# Usage
crawler = CrawlerPool(concurrency=30, max_retries=3)
urls = [f"https://example.com/product/{i}" for i in range(500)]
results = asyncio.run(crawler.crawl(urls, country="us"))
print(f"Success: {crawler.stats['success']}, Failed: {crawler.stats['failed']}")

Component 4: Parser

The parser transforms raw HTML into structured data. Keep parsing logic separate from crawling — this makes it testable, reusable, and easy to update when target sites change.

from dataclasses import dataclass
from typing import Optional
from bs4 import BeautifulSoup
import json
@dataclass
class ProductData:
    url: str
    title: Optional[str] = None
    price: Optional[float] = None
    currency: Optional[str] = None
    availability: Optional[str] = None
    rating: Optional[float] = None
    review_count: Optional[int] = None
    parsed_at: Optional[str] = None
class ProductParser:
    """Extracts structured product data from HTML."""
    def parse(self, url: str, html: str) -> ProductData:
        soup = BeautifulSoup(html, "html.parser")
        data = ProductData(url=url)
        try:
            data.title = self._extract_text(soup, "h1.product-title")
            data.price = self._extract_price(soup)
            data.currency = self._extract_currency(soup)
            data.availability = self._extract_text(soup, ".availability-status")
            data.rating = self._extract_rating(soup)
            data.review_count = self._extract_review_count(soup)
            data.parsed_at = time.strftime("%Y-%m-%dT%H:%M:%SZ", time.gmtime())
        except Exception as e:
            logger.error(f"Parse error for {url}: {e}")
        return data
    def _extract_text(self, soup, selector: str) -> Optional[str]:
        el = soup.select_one(selector)
        return el.get_text(strip=True) if el else None
    def _extract_price(self, soup) -> Optional[float]:
        el = soup.select_one("[data-price], .price, .product-price")
        if not el:
            return None
        price_text = el.get("data-price") or el.get_text(strip=True)
        # Remove currency symbols and parse
        cleaned = "".join(c for c in price_text if c.isdigit() or c == ".")
        return float(cleaned) if cleaned else None
    def _extract_currency(self, soup) -> Optional[str]:
        el = soup.select_one("[data-currency], .currency")
        return el.get("data-currency") or el.get_text(strip=True) if el else None
    def _extract_rating(self, soup) -> Optional[float]:
        el = soup.select_one("[data-rating], .rating-value")
        if el:
            val = el.get("data-rating") or el.get_text(strip=True)
            try:
                return float(val)
            except ValueError:
                return None
        return None
    def _extract_review_count(self, soup) -> Optional[int]:
        el = soup.select_one(".review-count, [data-reviews]")
        if el:
            text = el.get("data-reviews") or el.get_text(strip=True)
            digits = "".join(c for c in text if c.isdigit())
            return int(digits) if digits else None
        return None
# Usage
parser = ProductParser()
for result in results:
    if result["success"]:
        product = parser.parse(result["url"], result["body"])
        print(f"{product.title}: ${product.price}")

Component 5: Storage

Persist parsed data with versioning and deduplication. Use upserts to handle re-crawls gracefully.

import psycopg2
from psycopg2.extras import execute_values
from datetime import datetime
class DataStore:
    """Persists scraped data with upsert and versioning."""
    def __init__(self, dsn: str):
        self.conn = psycopg2.connect(dsn)
        self._ensure_tables()
    def _ensure_tables(self):
        with self.conn.cursor() as cur:
            cur.execute("""
                CREATE TABLE IF NOT EXISTS products (
                    url TEXT PRIMARY KEY,
                    title TEXT,
                    price NUMERIC(10,2),
                    currency VARCHAR(3),
                    availability TEXT,
                    rating NUMERIC(3,2),
                    review_count INTEGER,
                    first_seen_at TIMESTAMPTZ DEFAULT NOW(),
                    last_updated_at TIMESTAMPTZ DEFAULT NOW()
                );
                CREATE TABLE IF NOT EXISTS price_history (
                    id SERIAL PRIMARY KEY,
                    url TEXT REFERENCES products(url),
                    price NUMERIC(10,2),
                    recorded_at TIMESTAMPTZ DEFAULT NOW()
                );
            """)
            self.conn.commit()
    def upsert_products(self, products: list[ProductData]):
        """Insert or update products, recording price changes."""
        with self.conn.cursor() as cur:
            for product in products:
                if product.price is None:
                    continue
                # Check if price changed
                cur.execute(
                    "SELECT price FROM products WHERE url = %s",
                    (product.url,)
                )
                row = cur.fetchone()
                # Upsert product
                cur.execute("""
                    INSERT INTO products (url, title, price, currency, availability,
                                          rating, review_count, last_updated_at)
                    VALUES (%s, %s, %s, %s, %s, %s, %s, NOW())
                    ON CONFLICT (url) DO UPDATE SET
                        title = EXCLUDED.title,
                        price = EXCLUDED.price,
                        currency = EXCLUDED.currency,
                        availability = EXCLUDED.availability,
                        rating = EXCLUDED.rating,
                        review_count = EXCLUDED.review_count,
                        last_updated_at = NOW()
                """, (
                    product.url, product.title, product.price,
                    product.currency, product.availability,
                    product.rating, product.review_count,
                ))
                # Record price history if changed
                if row is None or float(row[0]) != product.price:
                    cur.execute(
                        "INSERT INTO price_history (url, price) VALUES (%s, %s)",
                        (product.url, product.price)
                    )
            self.conn.commit()
    @property
    def product_count(self) -> int:
        with self.conn.cursor() as cur:
            cur.execute("SELECT COUNT(*) FROM products")
            return cur.fetchone()[0]
# Usage
store = DataStore("postgresql://user:pass@localhost:5432/scraper")
store.upsert_products(parsed_products)
print(f"Total products: {store.product_count}")

Component 6: Monitoring

Tie all components together with centralized monitoring. For detailed proxy-specific monitoring patterns, see our Monitoring Proxy Performance guide.

import time
import json
import logging
from datetime import datetime
class PipelineMonitor:
    """Monitors the entire scraping pipeline."""
    def __init__(self):
        self.logger = logging.getLogger("pipeline")
        self.stage_times = {}
        self.stage_counts = {}
    def start_stage(self, stage: str):
        self.stage_times[stage] = time.time()
    def end_stage(self, stage: str, item_count: int = 0):
        elapsed = time.time() - self.stage_times.get(stage, time.time())
        self.stage_counts[stage] = item_count
        self.logger.info(json.dumps({
            "timestamp": datetime.utcnow().isoformat(),
            "stage": stage,
            "duration_seconds": round(elapsed, 2),
            "items_processed": item_count,
            "items_per_second": round(item_count / elapsed, 1) if elapsed > 0 else 0,
        }))
    def report(self) -> dict:
        return {
            "stages": {
                stage: {
                    "items": self.stage_counts.get(stage, 0),
                }
                for stage in self.stage_counts
            },
            "timestamp": datetime.utcnow().isoformat(),
        }
# Usage within the full pipeline
monitor = PipelineMonitor()
# Stage 1: Schedule
monitor.start_stage("schedule")
urls = scheduler.dequeue(batch_size=500)
monitor.end_stage("schedule", len(urls))
# Stage 2: Crawl
monitor.start_stage("crawl")
results = asyncio.run(crawler.crawl([u["url"] for u in urls]))
monitor.end_stage("crawl", len(results))
# Stage 3: Parse
monitor.start_stage("parse")
products = [parser.parse(r["url"], r["body"]) for r in results if r["success"]]
monitor.end_stage("parse", len(products))
# Stage 4: Store
monitor.start_stage("store")
store.upsert_products(products)
monitor.end_stage("store", len(products))
print(json.dumps(monitor.report(), indent=2))

Putting It All Together

Here is the complete pipeline that connects all six components into a single, runnable scraping system.

import asyncio
import logging
logging.basicConfig(level=logging.INFO)
async def run_pipeline():
    # Initialize components
    scheduler = CrawlScheduler()
    crawler = CrawlerPool(concurrency=30, max_retries=3)
    parser = ProductParser()
    store = DataStore("postgresql://user:pass@localhost:5432/scraper")
    monitor = PipelineMonitor()
    # Schedule crawls
    scheduler.add_schedule(
        name="daily_products",
        urls=[f"https://example.com/product/{i}" for i in range(1, 501)],
        interval_hours=24,
        priority=8,
    )
    # Main loop
    while True:
        # 1. Check schedules and enqueue URLs
        monitor.start_stage("schedule")
        scheduler.tick()
        batch = scheduler.dequeue(batch_size=100)
        monitor.end_stage("schedule", len(batch))
        if not batch:
            await asyncio.sleep(60)
            continue
        # 2. Crawl
        monitor.start_stage("crawl")
        urls = [item["url"] for item in batch]
        results = await crawler.crawl(urls, country="us")
        successful = [r for r in results if r.get("success")]
        monitor.end_stage("crawl", len(successful))
        # 3. Parse
        monitor.start_stage("parse")
        products = []
        for result in successful:
            try:
                product = parser.parse(result["url"], result["body"])
                products.append(product)
            except Exception as e:
                logging.error(f"Parse error: {e}")
        monitor.end_stage("parse", len(products))
        # 4. Store
        monitor.start_stage("store")
        store.upsert_products(products)
        monitor.end_stage("store", len(products))
        # 5. Report
        logging.info(f"Pipeline: {monitor.report()}")
        logging.info(f"Crawler stats: {crawler.stats}")
        # Wait before next batch
        await asyncio.sleep(5)
asyncio.run(run_pipeline())

Production Deployment Patterns

Horizontal Scaling

Scale crawlers independently from schedulers and parsers. Run multiple crawler instances consuming from the same Redis queue.

Component	Scaling Strategy	Typical Scale
Scheduler	Single instance (leader election)	1 instance
URL Queue	Redis cluster or managed queue	1 cluster
Crawler Pool	Horizontal pod scaling	2-20 instances
Proxy Layer	Managed by ProxyHat	N/A (external)
Parser	Co-located with crawler or separate	1:1 with crawlers
Storage	Database replication	1 primary + replicas
Monitoring	Centralized aggregation	1 instance

Error Recovery

• Crawler crash: URLs remain in Redis queue. New crawler picks them up automatically.
• Proxy failures: The middleware layer retries with fresh IPs. Sustained failures trigger alerts.
• Parser failures: Raw HTML is stored in a dead-letter queue for manual inspection and parser updates.
• Database failures: Parsed data buffers in memory/disk with write-ahead logging until the DB recovers.

Data Quality Checks

class DataQualityChecker:
    """Validates parsed data before storage."""
    def check(self, product: ProductData) -> list[str]:
        issues = []
        if not product.title:
            issues.append("missing_title")
        if product.price is not None and product.price <= 0:
            issues.append("invalid_price")
        if product.price is not None and product.price > 100000:
            issues.append("suspicious_price")
        if product.rating is not None and (product.rating < 0 or product.rating > 5):
            issues.append("invalid_rating")
        return issues
    def filter_valid(self, products: list[ProductData]) -> list[ProductData]:
        valid = []
        for product in products:
            issues = self.check(product)
            if issues:
                logger.warning(f"Data quality issues for {product.url}: {issues}")
            else:
                valid.append(product)
        return valid
# Integrate into pipeline
checker = DataQualityChecker()
valid_products = checker.filter_valid(products)
store.upsert_products(valid_products)

The best scraping architecture is one you can reason about. Every component should answer three questions: What does it do? How does it fail? How does it recover?

For the proxy layer component, see Building a Proxy Middleware Layer. For optimizing crawler throughput, read Scaling Proxy Requests with Concurrency Control. For browser-based crawling, see Rotating Proxies with Playwright. For anti-detection strategies, explore how to scrape without getting blocked.

Get started with Python SDK, Node SDK, or Go SDK for proxy integration. Explore ProxyHat pricing and documentation to power your scraping architecture.

Frequently Asked Questions
